Stamping/ Stacking Robot SDCX RMD-300/200/160/120/35/08/110/20/50

Intshayelelo emfutshane yemveliso

I-robot ye-stamping isetyenziselwa ukupakisha, ukuchithwa, ukuthutha kunye neminye imisebenzi kwimimandla yokupakisha, isiselo, imboni yeekhemikhali, ukutya, njl., Ukubonelela abasebenzisi ngesethi epheleleyo yezisombululo zokusebenza ngokukhawuleza, ezikhuselekileyo, eziguquguqukayo, ezichanekileyo kunye nokubeka indawo.

QHAGAMSHELANA NATHI

Iinkcukacha zeMveliso

Iithegi zeMveliso

Iiparamitha zobuGcisa

Umzekelo No.	Isidanga seNkululeko	Imo yokuqhuba	Ukuhlawula (KG)	Ukuchaneka okuphindiweyo (mm)	Uluhlu lwesindululo (°)				Esona santya siphezulu (°/s)				Umthwalo ovumelekileyo we-inetia yesihlahla (kg·m²)	Isingqi sesetyhula (umjikelo/iyure)	Irediyasi yentshukumo (mm)	Ubunzima beNdawo (ikg)
Umzekelo No.	Isidanga seNkululeko	Imo yokuqhuba	Ukuhlawula (KG)	Ukuchaneka okuphindiweyo (mm)	J1	J2	J3	J4	J1	J2	J3	J4	Umthwalo ovumelekileyo we-inetia yesihlahla (kg·m²)	Isingqi sesetyhula (umjikelo/iyure)	Irediyasi yentshukumo (mm)	Ubunzima beNdawo (ikg)
I-SDCX-RMD300	4	AC servo drive	300	±0.5	±180	± +100~-44	± +121~-15	±360	85	90	100	190	134	1000^③	3150	1500
I-SDCX-RMD200	4	AC servo drive	200	±0.3	±180	± +100~-44	± +121~-15	±360	105	107	114	242	78	1300^③	3150	1500
I-SDCX-RMD160	4	AC servo drive	160	±0.3	±180	± +100~-44	± +121~-15	±360	123	123	128	300	78	1500^③	3150	1500
I-SDCX-RMD120	4	AC servo drive	120	±0.3	±180	± +100~-44	± +121~-15	±360	128	126	135	300	78	1560^③	3150	1500
I-SDCX-RMD50	4	AC servo drive	50	±0.2	±178	± +90~-40	± +65~-78	±360	171	171	171	222	4.5	1700^②	2040	660
I-SDCX-RMD20	4	AC servo drive	20	±0.08	±1170	± +115~-25	± +70~-90	±360	170	170	185	330	0.51	1780^①	1720	256
I-SDCX-RMD08	4	AC servo drive	8	±0.08	±170	± +90~-40	± +68~-90	±360	251	195	195	367.5	0.25	1800^①	1433	180

Amagqabantshintshi:

① Umzila wovavanyo yi-150mm ukuphakama kunye ne-1000mm ububanzi, kwaye ixesha lomjikelezo wangempela lichaphazelekayo kwiimeko zokusebenza zangempela;

② Umzila wokuvavanya ngu-200mm ubude kunye no-1000mm ububanzi, kwaye ixesha lomjikelezo wangempela lichaphazelekayo kwiimeko zokusebenza zangempela;

③ Umzila wovavanyo yi-400mm ukuphakama kunye ne-2000mm ububanzi, kwaye ixesha lomjikelezo wangempela lichatshazelwa ziimeko zokusebenza zangempela;

Kulumkele ukudibana neegesi ezinokutsha, eziqhumayo kunye nezityayo kunye nolwelo;Yenza ukuba ungatshizwa ngamanzi, ioli kunye nothuli;Zigcine kude nemithombo yengxolo yombane (iplasma)
